Fujitsu Airstage Multi-Split KMTE Wall-Mounted - R32
Designed for use within 2–5 indoor unit multi-split configurations, the Fujitsu AIRSTAGE KM Series wall-mounted units deliver powerful, efficient year-round comfort when connected to a single multi-split outdoor system. Featuring high-efficiency inverter technology, ultra-quiet operation, and eco-friendly R32 refrigerant, these units provide reliable heating and cooling for larger rooms and open-plan spaces. With strong seasonal efficiency ratings and optional smart device connectivity for remote control, the KM Series combines modern aesthetics, flexible multi-zone compatibility, and dependable performance—making it an ideal choice for homes and light commercial environments requiring efficient multi-room climate control.
|
Model Reference |
Cool Capacity (kW) |
Heat Capacity (kW) |
Max Pipe (m) |
EuP Lot 10 Energy Rating |
Suggested MCB (A) |
Pipe Size Gas (inch) |
Pipe Size Liquid (inch) |
Electrical Supply |
Wi-Fi Control |
||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Indoor Unit | SCOP | SEER | |||||||||
| ASEG18KMTE | 5.2 | 6.3 | Please refer to
2 Unit to 5 Unit Multi-Split Condensers - R32 for more information or contact Oceanair. |
1/2 | 1/4 | Single | Optional | ||||
| ASEG24KMTE | 7.1 | 8.0 | 1/2 | 1/4 | Single | Optional | |||||
| For more information, see Technical Specifications. |
|||||||||||
Key features
High-Efficiency Performance for Maximum Energy Savings
This system delivers exceptional energy efficiency through its advanced lambda-shaped hybrid heat exchanger, which significantly improves heat transfer to achieve top-level SEER and SCOP ratings. Combined with a large Ø107 cross-flow fan that moves air efficiently even at reduced power and the use of eco-friendly R32 refrigerant, the unit provides powerful, energy-saving performance designed for modern, low-consumption climate control.
Convenient Smart Device Control Anywhere
With the optional WLAN adapter (UTY-TFSXH3), the air conditioner can be controlled remotely from any location using your smartphone or tablet. By installing the AIRSTAGE Mobile app, users gain full access to operating modes, temperature settings, and scheduling features, enabling effortless and flexible climate management whether at home or away.
Simplified Installation with Improved Pipe Access
The redesigned indoor unit allows easier access to the flare pipe connection, featuring a removable lower cover for left-side piping and an updated wall hook bracket for smoother center-outlet installations. With wider service space and an installer-friendly layout, the system ensures faster, more efficient setup and maintenance.
Flexible Multi-Zone Design for Precise Comfort Control
Supports a wide range of applications, from open-plan offices to retail environments, with up to four indoor units connected to a single outdoor unit. Engineers can select and position indoor units based on floor layout, occupancy levels, and solar gain, ensuring balanced airflow distribution and accurate load matching for consistent comfort across every zone.
Multi-Split KMTE Series Specification Table
| Technical Data | Model Number | ||
|---|---|---|---|
| ASEG18KMTE | ASEG24KMTE | ||
| Power Source | Single phase, ~230 V, 50 Hz | Single phase, ~230 V, 50 Hz | |
| kW Class | 5.0 | 7.0 | |
| Sound Pressure Level Cooling - H/M/L/Q (dBA) | 45 / 40 / 35 / 29 | 49 / 40 / 35 / 29 | |
| Sound Pressure Level Heating - H/M/L/Q (dBA) | 46 / 40 / 35 / 29 | 49 / 40 / 35 / 29 | |
| Airflow Rate (Cooling) High (m3/h) | 980 | 1,170 | |
| Airflow Rate (Heating) High (m3/h) | 1,020 | 1,170 | |
| Net Dimensions H x W x D / Weight (mm / kg) | 280 × 980 × 240 / 12.5 | 280 × 980 × 240/ 12.5 | |
| Remote Controller Type (Supplied With Unit | Wireless | Wireless | |
| Connection Pipe Diameter - Liquid/Gas (Inch) | 1/4 & 1/2 | 1/4 & 1/2 | |
This table is intended as a guide only. Please consult manufacturer's information for more details.
