Fujitsu Airstage Multi-Split KRTA Under Ceiling - R32
The Fujitsu Airstage KRTA Under Ceiling Units in an R32 multi-split system (2–5 indoor units) deliver stylish, space-saving heating and cooling for commercial and residential spaces. Red Dot Design Award Winner 2020, the slim KRTA ceiling units blend discreetly between the wall and ceiling while providing efficient, evenly distributed airflow. The flexible multi-split configuration allows multiple indoor units to connect to a single outdoor unit, reducing external space requirements and enabling adaptable system design. Using eco-friendly R32 refrigerant and advanced inverter technology, this system offers efficient, reliable comfort with outstanding design credentials.
|
Model Reference |
Capacity kW Class |
Max Pipe (m) |
EuP Lot 10 Energy Rating |
Suggested MCB (A) |
Pipe Size Gas (inch) |
Pipe Size Liquid (inch) |
Electrical Supply |
Wi-Fi Control |
|||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Indoor Unit | SCOP | SEER | |||||||||
| ABEG18KRTA | 5.0 | Please refer to
2 Unit to 5 Unit Multi-Split Condensers - R32 for more information or contact Oceanair. |
1/2 | 1/4 | Single | Optional | |||||
| ABEG22KRTA | 6.0 | 1/2 | 1/4 | Single | Optional | ||||||
| For more information, see Technical Specifications. |
|||||||||||
Key features
Central Control System Integration (Optional)
For enhanced building management, the system can link with a range of central control platforms. By integrating via optional MODBUS or KNX interfaces, users can centrally monitor and control not only air conditioning but also other facility equipment, providing a unified and efficient control solution.
Red Dot Award-Winning Design
The Fujitsu Ceiling Suspended Unit features an award-winning, slimline design recognised with the Red Dot Design Award 2020. Its clean, modern profile integrates seamlessly into commercial and contemporary interiors while delivering efficient, evenly distributed airflow for reliable comfort.
Optional Remote Smart Control
With the optional Wi-Fi adaptor, the Fujitsu Ceiling Suspended Unit can be controlled remotely using the Fujitsu Airstage app. Adjust temperature settings, operating modes, and schedules from anywhere, giving you greater convenience, energy efficiency, and control—whether on-site or away.
Flexible Multi-Zone Design for Precise Comfort Control
Supports a wide range of applications, from open-plan offices to retail environments, with up to four indoor units connected to a single outdoor unit. Engineers can select and position indoor units based on floor layout, occupancy levels, and solar gain, ensuring balanced airflow distribution and accurate load matching for consistent comfort across every zone.
Multi-Split KRTA Series Specification Table
| Technical Data | Model Number | |||||||
|---|---|---|---|---|---|---|---|---|
| ABEG18KRTA | ABEG22KRTA | |||||||
| Power Source | Single phase, ~230 V, 50 Hz | |||||||
| kW Class | 5.0 | 6.0 | ||||||
| Sound Pressure Level Cooling H/M/L/Q dB(A) | 38/36/33/31 | 42/37/34/31 | ||||||
| Sound Pressure Level Heating H/M/L/Q dB(A) | 38/36/33/31 | 42/37/34/31 | ||||||
| Sound Power Level Indoor Cooling/Heating High dB(A) | 53/53 | 57/57 | ||||||
| Airflow Rate Cooling / Heating High m³/h | 840/840 | 900/900 | ||||||
| Remote Controller Type | No Controller Supplied with this Unit. Please Order Separately | |||||||
| Net Dimensions Indoor (H × W × D) mm | 235 × 1,080 × 705 | 235 × 1,080 × 705 | ||||||
| Weight kg | 24 | 24 | ||||||
| Connection Pipe Diameter (Liquid / Gas) mm | 6.35/12.70 | 6.35/12.70 | ||||||
This table is intended as a guide only. Please consult manufacturer's information for more details.
