Reliance RWC 1/2" MBSP X 15mm CPT15 Pressure & Temperature Relief Valve PTEM540020
The Reliance Valves Predator Pressure Reducing Valve helps to reduce water wastage and energy consumption by decreasing pressure from the mains water supply.
Read more- Cartridge-style construction for long service life and reliable operation
- 1/2" MBSP threaded inlet with 15 mm compression outlet
- 6.0 bar pressure and temperature relief rating
- 95 mm temperature probe length
- WRAS approved
Description
The Reliance CPT15 pressure and temperature relief valve protects unvented hot water systems from excessive temperature and pressure caused by control failure. Installed in the upper section of the cylinder, it responds to high temperatures where risk is greatest.
If water temperature exceeds 95 °C, the wax-filled sensor activates the valve to discharge safely to waste. In pressure-only conditions, the valve remains closed until the set pressure limit is reached, then opens to relieve excess pressure and protect the system
- Cartridge-style construction for long service life and reliable operation
- 1/2" MBSP threaded inlet with 15 mm compression outlet
- 6.0 bar pressure and temperature relief rating
- 95 mm temperature probe length
- WRAS approved
* See technical attachments for more details.
Specification
Downloads
PTEM540020 Data Sheet
